Standard Square Center Wheel Spacers
These are premium new dual wheel adaptors for you garden tractor. They will fit Cub Cadet, John Deere, Simplicity, AC, Sears and most garden tractors that use the 12" rim with the 5 bolts on a 4 1/2" diameter bolt circle. These rims were widely used between most lawn and garden tractor manufactures. These have been used on 6 and 8 wheel swamp buggies and trenchers. Not recommended for speeds over 10 MPH, Competition Pulling Use or High Speed Applications. Our spacers are made with 5/16" thick, grade 50 steel, outer plates. The inner plate is chamfered to accept wheel studs or nuts. The square tube is a 2 1/2 x 2 1/2 x 3/16 wall tube. We fully weld the plates to the tubes on the inside and outside, providing maximum strength, not like some out there that just weld a plate to a tube. Then we use fine thread, grade 5, zinc coated bolts thru the outer plates and weld the backsides. The reason for this is that the bolt can be cut out and a new one welded in. Tapped plates are not as easily repairable! We provide fine thread, chrome plated acorn nuts to finish out the package. Cover plate are included to slide over the studs to cover up the end of the tube. Ships unpainted unless you purchase powder coating, below.
Powder Coating Available - Add to your cart with the buttons below.
Powder Coat Black, $40.00 / set,
Powder Coat Cub White, $40.00 / set,
Powder Coat JD Green, $40.00 / set,
Large Round Center Wheel Spacers
We have had requests for a larger center dual wheel spacer that will clear over some brands. The larger center is 3" clear inside diameter. These are premium new dual wheel adaptors for you garden tractor. They will fit Cub Cadet, John Deere, Simplicity, AC, Sears and most garden tractors that use the 12" rim with the 5 bolts on a 4 1/2" diameter bolt circle. These rims were widely used between most lawn and garden tractor manufactures. Have been used on 6 and 8 wheel swamp buggies and trenchers. Not recommended for speeds over 10 MPH, Competition Pulling Use or High Speed Applications. Our spacers are made with 5/16" thick, grade 50 steel, outer plates. The inner plate is chamfered to accept wheel studs or nuts. The square tube is a 3" x 3/16" wall tube. We fully weld the plates to the tubes on the inside and outside, providing maximum strength, not like some out there that just weld a plate to a tube. Then we use fine thread, grade 5, zinc coated bolts thru the outer plates and weld the backsides. The reason for this is that the bolt can be cut out and a new one welded in. Tapped plates are not as easily repairable! We provide fine thread, chrome plated acorn nuts to finish out the package. Cover plate are included to slide over the studs to cover up the end of the tube. Ships unpainted unless you purchase powder coating, below.
Powder Coating Available - Add to your cart with the buttons below.
Powder Coat Black, $40.00 / set,
Powder Coat Cub White, $40.00 / set,
Powder Coat JD Green, $40.00 / set,
4 Bolt Standard Square Center Wheel Spacers
We even make a 4 Bolt Dual Wheel Spacer. These are premium new dual wheel adaptors for you garden tractor. They will fit Cub Cadet, John Deere, Simplicity, AC, Sears and most garden tractors that use the 8" thru 12" rim with the 4 bolts on a 4" (101mm) diameter bolt circle. These rims were widely used between most lawn and garden tractor manufactures. Have been used on 6 and 8 wheel swamp buggies and trenchers. Not recommended for speeds over 10 MPH, Competition Pulling Use or High Speed Applications. Comes with 1/2" fine thread studs and tapered lug nuts. We do not make these with a round tube. The 3 1/2" outer diameter tube does not allow enough room for the studs, so we can only use square tube.
Our spacers are made with 5/16" thick, grade 50 steel, outer plates. The inner plate is chamfered to accept wheel studs or nuts. The square tube is a 2 1/2 x 2 1/2 x 3/16 wall tube. We fully weld the plates to the tubes on the inside and outside, providing maximum strength, not like some out there that just weld a plate to a tube. Then we use fine thread, grade 5, zinc coated bolts thru the outer plates and weld the backsides. The reason for this is that the bolt can be cut out and a new one welded in. Tapped plates are not as easily repairable! We provide fine thread, chrome plated acorn nuts to finish out the package. Cover plate are included to slide over the studs to cover up the end of the tube. Ships unpainted unless you purchase powder coating, below.Powder Coating Available - Add to your cart with the buttons below.
Powder Coat Black, $40.00 / set,
Powder Coat Cub White, $40.00 / set,
Powder Coat JD Green, $40.00 / set,
Garden Tractor Dual Wheel Spacer Cover Plates
Covers up the end of the Dual Wheel Spacers above. Raw steel - unpainted. Sold in pairs, Unpainted.
$22.00 / pair, PN# CC-01-055 (5 Bolt)
$22.00 / pair, PN# CC-01-054 (4 Bolt)
Powder Coating Available - Add to your cart with the buttons below.
Powder Coat Black, $20.00 / set,
Powder Coat Cub White, $20.00 / set,
Powder Coat JD Green, $20.00 / set,
Garden Tractor Wheel Spacer Plates
$42.00 / pair, PN# CC-01-011
2 - 5/16" Plates - spaces your wheels out 5/16" on each side Made from 5/16" Grade 50 Steel. Unpainted.
Billet Aluminum Wheel Spacers
These are billet aluminum spacers for moving your tires out 1". They are a 5 bolt on a 4.5" bolt circle to a 5 bolt on a 4.5" bolt circle. The outer studs are 13 mm and you will have to drill your rims out a hair with a 1/2" drill to git the existing rims on if they are the small 7/16" holes. Some rims for some garden tractors are 13 mm already. Come with a pair of cover plates to cover the hole in the middle of your rim. Sold in Pairs, Unpainted.
1.25" Billet Aluminum Wheel Spacers Reducers
$145.00 / set, PN# CC-01-046
These are billet aluminum spacers for adapting the larger 5 bolt x 4.75 rims to your garden tractor. They are a 5 bolt on a 4.5" bolt circle (to bolt to your tractor) to a 5 bolt on a 4.75" bolt circle (Like a 15" car bolt pattern). The outer studs are 13 mm. Sold in Pairs, Unpainted.
7/16 Fine Thread Bulge Wheel Nuts
$47.00 / 10 pcs., PN# CC-01-049
If your running our billet aluminum wheel spacers, and you are running wheel studs, then it is a good idea to use these wheel nuts that are bulged for the best holding power that you can get. Fine Thread. Sold in sets of 10
7/16 Fine Thread Bulge Wheel Lug Bolts
$60.00 / 10 pcs., PN# CC-01-050
If your running our billet aluminum wheel spacers, then it is a good idea to use these wheel studs that are bulged for the best holding power that you can get. 7/16 FIne Thread. Sold in sets of 10
Cub Cadet Wheel Spacer Studs / Nut Combo
$92.00 / 10 pcs., PN# CC-01-048
These allow you to bolt your inner rims on, tighten them down, then bolt on your spacer. This will allow you to put your duals on and off easier. These are similiar to the original ones sold with the original Cub Spacers. Sold in sets of 10
